The large PD22MH flanged valves is pilot operated with a requirement of at least 0.3 Bar minimum pressure, the valve is energised to open by a small coil available in AC and DC. The valve body is made up from cast iron with a Viton seal. The PD22MH series valve are mainly used for applications like municipal mains water supply valve for commercial buildings or used as a large air shut off valve.

PD22MH Flanged Series, N/Closed, Pilot Operated, Solenoid Valves

PD22MH Flanged Series, N/Closed, Pilot Operated, Solenoid Valves. The Valve Body is made of Cast Iron. Seals available is VITON. The Operating pressure Range is 0,3 to 8(DC)/12(AC) Bar. Because of the Body Material and seal options these valves can be used with liquids and gasses compatible with Cast Iron and Viton. The only further requirement is viscosity below 40 Centistokes and a Minimum available pressure of 0,3 Bar(3 Meter Head). Thus not suitable for Gravity feed applications.


View PDF data sheet for specific information.
PD22MH Flanged Series, N/Closed, Pilot Operated, Solenoid Valves

PD22MH Flanged Series, N/Closed, Pilot Operated, Solenoid Valves. The Valve Body is made of Cast Iron. Seals available is VITON. The Operating pressure Range is 0,3 to 8(DC)/12(AC) Bar. Because of the Body Material and seal options these valves can be used with liquids and gasses compatible with Cast Iron and Viton. The only further requirement is viscosity below 40 Centistokes and a Minimum available pressure of 0,3 Bar(3 Meter Head). Thus not suitable for Gravity feed applications.


View PDF data sheet for specific information.

3" Flanged, Cast Iron & VITON, 0,3 to 8/12 Bar (CDHRS coil excl)
PART NO : PD22MH80S30
SIZE/DESCRIPTION:
3" Flanged, Cast Iron & VITON, 0,3 to 8/12 Bar (CDHRS coil excl)

PRICE FROM: R 7417.50(Nett)
QUANTITY:


QUANTITY:
PART NO : PD22MH100S40
SIZE/DESCRIPTION:
4" Flanged, Cast Iron & VITON, 0,3 to 8/12 Bar (CDHRS coil excl)

PRICE FROM: R 9619.75(Nett)
QUANTITY:


QUANTITY:

Large Solenoid Valve Coil

220VAC Solenoid,24VDC Solenoid,12VDC Solenoid,110VAC Solenoid -CDHRS Series COIL SOLENOID used on solenoid Valve Types PD22MH

Large Solenoid Valve Coil

220VAC Solenoid,24VDC Solenoid,12VDC Solenoid,110VAC Solenoid -CDHRS Series COIL SOLENOID used on solenoid Valve Types PD22MH


CDHRS Coil & Plug for DHD/PD22MH VALVES( 400325-117-1)XXX-Specifies Voltage.
PART NO : CDHRS 30A-XXX
SIZE/DESCRIPTION:
CDHRS Coil & Plug for PD22MH VALVES( 400325-117-1)XXX-Specifies Voltage.

PRICE FROM: R 593.40
QUANTITY:


QUANTITY:
