1/8" PX22 Series - 2/2 N/Closed Direct operated Valves. The Valve Body is made of Brass. Seals available is Viton. Orifice 1,5 mm. The Operating pressure Range is 0 to 16 Bar (AC) 13 Bar (DC). (Click the "View PDF" below for complete information)

View PDF data sheet for specific information.

PLP23 Series - 2/2 N/Open Pilot Operated Diaphragm Valves. The Valve Body is made of Brass with a Viton seal. The Operating pressure Range is 0,3 to 8/13 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses which is compatible with Brass and Viton. The only further requirement is viscosity below 40 Centistokes and a Minimum available pressure of 0,3 Bar(3 Meter Head). Thus not suitable for Gravity feed applications.

View PDF data sheet for specific information.

1/4" PLM222 Series - 2/2 N/Closed, Direct Acting Solenoid Valve. The Valve Body is made of BRASS. Seals are VITON - up to 140 Deg C. Orifice 1mm, 2mm or 2.5mm. The Operating Pressure Range depends on the orifice size and voltage, see PDF data sheet. (Click the "View PDF" below for complete information)

View PDF data sheet for specific information.

1/4" PLT32 Brass Series- SCE320 3 Way Normally Closed & Diverter Valve, Direct Acting. The Valve Body is made of Brass. Seals are VITON. Because of the Body Material and seal options these valves can be used in with different Liquids, oils and gasses with 99% compatibility. This valve is suitable for Gravity feed applications.

View PDF data sheet for specific information.

P2W22 Series - 2/2 N/Closed Assisted Lift Diaphragm Valves. The Valve Body is made of BRASS. Seals available is NBR, VITON and EPDM. The Operating pressure Range is 0 to 10 Bar. Suitable for Gravity feed applications (Zero) 0 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 40 Centistokes. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available.

View PDF data sheet for specific information.

PLW22 Series - 2/2 N/Closed, Direct Acting Solenoid Valve. The Valve Body is made of BRASS. Seals are VITON. Hose Barb Fitting 5mm, Orifice 2.5mm. Pressure 0-6 Bar. Voltage available 12VDC ONLY, see PDF data sheet for more technical specs. (Click the "View PDF" below for complete information)

View PDF data sheet for specific information.

PLZ22 High Pressure Series - (Pressure is stated for Water & Air -Not applicable for High Viscosity media)(See data sheet for detailed spec).2/2 N/Closed Direct Acting Solenoid Valve. The Valve Body is made of Stainless Steel 316. Seals available is VITON, EPDM, PTFE & PEEK. Orifice 1.5mm, 2mm, 2.5mm & 3mm. See PDF for each valve size pressure range.

View PDF data sheet for specific information.

PLZ22 Brass High Pressure Series for Compressor, N/Closed, Pilot Operated Solenoid Valve. The Valve Body is made of Brass with a PEEK seal. Orifice 8mm. The Operating pressure Range is 1 to 150 Bar.(Pressure is stated for Water & Air -Not applicable for High Viscosity media)(See data sheet for detailed spec).

View PDF data sheet for specific information.

PGH22 Brass Series - 2/2 N/Closed Direct Acting Solenoid Valve. The Valve Body is made of Brass. Seals available is VITON. Orifice 4mm. The operating depends on orifice and voltage - see PDF for more technical specs.

View PDF data sheet for specific information.

PGH23 Brass Series - 2/2 N/Open Direct Acting Solenoid Valve. The Valve Body is made of Brass. Seals available is VITON. Orifice 2mm. The operating depends on orifice and voltage - see PDF for more technical specs.

View PDF data sheet for specific information.

PLM23 Brass Series - 2/2 N/Open Direct Acting Solenoid Valve. The Valve Body is made of Brass. Seals available is VITON. Orifice 3 mm. The operating depends on orifice and voltage - see PDF for more technical specs.

View PDF data sheet for specific information.

1/4" PLT33 Brass Series- SCE320 3 Way Normally Open Valve, Direct Acting. The Valve Body is made of Brass. Seals are VITON. Because of the Body Material and seal options these valves can be used in with different Liquids, oils and gasses with 99% compatibility. This valve is suitable for Gravity feed applications.

View PDF data sheet for specific information.

PDS22BH Series - 2/2 N/Closed Pilot Operated, High Pressure Solenoid Valves. The Valve Body is made of Brass. Seals available is VITON. The Operating pressure Range is 0,3 to 16 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses which is compatible with Brass and Viton. The only further requirement is viscosity below 40 Centistokes and a Minimum available pressure of 0,3 Bar(3 Meter Head). Thus not suitable for Gravity feed applications. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available.

View PDF data sheet for specific information.

PLV32 Brass Series, Normally Closed 3/2 Valve, with 1/4" Ports and 1.5mm orifice, used for air gas, water & light oils. Direct Acting 0 to 7 Bar (pressure depends on voltage). The Valve Body consists of Brass & Viton Seals.

View PDF data sheet for specific information.

PQS22 High Pressure BRASS Series - 2/2 N/Closed Direct Acting Diaphragm Valves. The Valve Body is made of BRASS with standard VITON seal. The Operating pressure Range differs from orifice size and voltage. Suitable for Gravity feed applications (Zero) 0 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 20 Centistokes.

View PDF data sheet for specific information.

PLV33 Brass Series, Normally Open 3/2 Valve, with 1/4" Ports and 1.5mm orifice, used for air gas, water & light oils. Direct Acting 0 to 6 Bar (pressure depends on voltage). The Valve Body consists of Brass & Viton Seals.

View PDF data sheet for specific information.

PQS23 BRASS Series - 2/2 N/Open Direct Acting Diaphragm Valves. The Valve Body is made of BRASS with standard VITON seal. The Operating pressure Range 0 to 10 Bar. Suitable for Gravity feed applications (Zero) 0 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 20 Centistokes.

View PDF data sheet for specific information.

P2W22 & PQ22 Series - 2/2 N/Closed Direct Lift Diaphragm Valves. The Valve Body is made of 304 Stainless Steel. Seals available is VITON. The Operating pressure Range is 0 to 6 Bar (DC). WILL WORK FOR GRAVITY FEED Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 40 Centistokes. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available.

View PDF data sheet for specific information.

PLQS22 Brass Series, Anti Water Hammer & Low Power (NC), Pilot Operated Solenoid Valve. The Valve Body is made of Brass. Valve Seals are Buna (NBR) natural rubber seals. Maximum 60 Deg C.The Operating pressure Range is 1 to 16 Bar up to 1" and for Larger sizes 12 Bar Maximum. These Valves are Low cost and basic. Their use is for Clean water, Non Corrosive thin Liquids, Compressed Air and Non corrosive gases. (NOT SUITABLE FOR GRAVITY FEED APPLICATIONS) SPECIAL PRICE DISCOUNTS ONLY APPLY WHILE STOCK LASTS. The New Replacements Range is PLQM22.

View PDF data sheet for specific information.

PLGA22 High Pressure Diaphragm Series, N/Closed, Brass Solenoid Valve. The Valve Body is made of Brass. Seals are VITON. The Maximum Body Pressure is 50 Bar. (Pressure is stated for Water & Air -Not applicable for High Viscosity media)(See data sheet for detailed spec). Temperature up to 90 Deg Celsius.

View PDF data sheet for specific information.

PLQM22 Brass Series, Anti Water Hammer & Low Power (NC), Pilot Operated Solenoid Valve. The Valve Body is made of Brass. Valve Seals are VITON. The Operating pressure Range is 0,3 to 16 Bar for AC voltages and 10 Bar for DC voltages. These Valves are Low cost and basic. Their use is for Clean water, Non Corrosive thin Liquids, Compressed Air and Non corrosive gases. (NOT SUITABLE FOR GRAVITY FEED APPLICATIONS)

View PDF data sheet for specific information.

P3W23 Series - 2/2 N/Open Assisted Lift Diaphragm Valves. The Valve Body is made of BRASS. Seals available is NBR, VITON and EPDM. The Operating pressure Range is 0 to 6 Bar. Suitable for Gravity feed applications(Zero) 0 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 40 Centistokes.

View PDF data sheet for specific information.

PXD Series, 2/2 Way Brass Reduced Bore Electric Ball Valve. Voltage Supply is 5VDC with Swop Polarity Control (Detent). These Valves have switches that switch them off when they reach end of rotation. They have metal gears in the gearboxes. The actuator uses only milli-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP40 Body Material Brass Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: 5VDC Applications: It is used for Domestic Applications or small projects. We test these valves to full capacity for a minimum of 30 cycles before it is released for sale to ensure good quality.

View PDF data sheet for specific information.

PBVX2XX Brass Series, 2/2 Way FULL BORE Brass Electric Ball Valves. See data sheet for wiring options. These Valves have switches that switch them off when they reach end of rotation. Features: Motor Enclosure:IP67 Body Material Brass Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: See data sheet. Applications: It is used for Industrial Line Shutoff, home water, Solar water heaters and small automatic control equipment.

View PDF data sheet for specific information.

PFA Series, 2/2 Way Brass Electric Ball Valves. These Valves have switches that switch them off when they reach end of rotation. The valves-(2 Wires ONLY- Works Similar like Solenoid Valve and can be wired same). The N/C Valve will Close when POWER FAILS or when you switch it off (FAILSAFE/AUTO CLOSE on Power Fail). The N/O Valve will Open when POWER FAILS or when you switch it off (FAILSAFE/AUTO OPEN on Power Fail). The DC Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP65 Body Material Brass Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 80 Degrees C. Voltages: DC9-24V & AC110-220V (See Specific Stock Item) Applications: It is used for Domestic Line Shutoff, Home water systems, Solar water heaters and small automatic control equipment. We test these valves to full capacity in our test bench for a minimum of 10 cycles before it is released for sale to ensure good quality.

View PDF data sheet for specific information.

PGBVC Brass Series ,3/2 Way Brass FULL BORE Electric Ball Valves. (CAN BE USED AS NORMAL OPEN, CLOSED OR AS A FLOW DIVERTER VALVE). The three(3) Port Ball valve are also used as a solar change over valve, between Electric/Gas Geyser and Solar Heater,night to day. These Valves have switches that switch them off when they reach end of rotation. Features: Motor Enclosure:IP62 Body Material Brass Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 90 Degrees C. Voltages: DC9-24V and AC110-220V(See Specific Stock Item) Applications: It is used for Industrial Line Shutoff, home water, Solar water heaters and small automatic control equipment.

View PDF data sheet for specific information.

PBVT2XX Brass Ball Valve Series, 2/2 Way Full Bore with Timer Actuator. These Valves have switches that switch them off when they reach end of rotation. Stays open for selected time then closes for selected time. The DC Type uses only milli-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP62 Body Material Brass Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages:AC/DC9-24V and AC110-220V(See Specific Stock Item) Applications: It is used for Industrial Line Shutoff,home water, Solar water heaters and small automatic control equipment.

View PDF data sheet for specific information.

MATCH YOUR COILS BELOW TO YOUR VALVE TYPE PDS22, P2W22......
