OPEN SOLENOID VALVE(N/0)

We are a Registered "ESSENTIAL SERVICES" Company and is available during LOCKDOWN for:

1) Quotes to Everyone

2) Quote, Invoice and Supply of Essential Parts to "ESSENTIAL SERVICES" registered Companies during LOCKDOWN.

3) NON-ESSENTIALS will only be available after LOCKDOWN.

CONTACT: Call,WhatsApp or EMail: Markus & Bianca

Tel:(012) 661 8874 - Cell:061 444 2242
EMail: sales01@pneumatron.co.za OR valve2225@gmail.com


 SPECIALS - CLICK HERE

                  WHAT DO YOU NEED?

1) Electric Ball Valves- CLICK HERE
2)
General,Water Brass Solenoid Valves -  CLICK HERE
3) Low Cost Brass Valve - CLICK HERE
4) Stainless Steel Solenoid Valves - CLICK HERE
5) Steam Solenoid Valves - CLICK HERE
6) High Pressure Solenoid Valves - CLICK HERE
7) Pneumatic Solenoid Valves - CLICK HERE
8) Angle Seat Valves - CLICK HERE


NORMALLY OPEN Solenoid Valves will be in an OPEN state when NOT ENERGISED OR ELECTRICALLY POWERED. Once the Normally Open Valve is ENERGISED or POWER IS APPLIED the valve will CLOSE.


PCG23 Series, 1/4" Normally Open or Flow diverter , Stainless Solenoid Valves

1/4" PCG23 Series- 3 Way Normally Open & Diverter Valve, (Small flow 2.5mm ORIFICE INSIDE)Direct Acting 0 to 8 Bar for N/Open,0 to 8 Bar Diversion of flow. The Valve Body is made of 304 Stainless Steel. Seals are VITON. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. This valve is suitable for Gravity feed applications.


View PDF data sheet for specific information.
PCG23 Series, 1/4" Normally Open or Flow diverter , Stainless Solenoid Valves

1/4" PCG23 Series- 3 Way Normally Open & Diverter Valve, (Small flow 2.5mm ORIFICE INSIDE)Direct Acting 0 to 8 Bar for N/Open,0 to 8 Bar Diversion of flow. The Valve Body is made of 304 Stainless Steel. Seals are VITON. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. This valve is suitable for Gravity feed applications.


View PDF data sheet for specific information.

1/4" BSP, (Small flow 2.5mm ORIFICE INSIDE)Stainless Steel & Viton, 0 to 8 Bar (C19DX coil excl)
PART NO : PCG23SH02S02V
SIZE/DESCRIPTION:
1/4" BSP, (Small flow 2.5mm ORIFICE INSIDE)Stainless Steel & Viton, 0 to 8 Bar (C19DX coil excl)

PRICE FROM: R 1501.04
QUANTITY:


QUANTITY:

PLV33 Brass Series, Normally Open 3/2 Valve

PLV33 Brass Series, Normally Open 3/2 Valve, with 1/4" Ports and 1.5mm orifice, used for air gas, water & light oils. Direct Acting 0 to 6 Bar (pressure depends on voltage). The Valve Body consists of Brass & Viton Seals.


View PDF data sheet for specific information.
PLV33 Brass Series, Normally Open 3/2 Valve

PLV33 Brass Series, Normally Open 3/2 Valve, with 1/4" Ports and 1.5mm orifice, used for air gas, water & light oils. Direct Acting 0 to 6 Bar (pressure depends on voltage). The Valve Body consists of Brass & Viton Seals.


View PDF data sheet for specific information.

1/4" BSP, 3 Way, N/Open, Brass & Viton, 0 to 6 Bar (C13 coil excl)
PART NO : PLV33BH15S02V
SIZE/DESCRIPTION:
1/4" BSP, 3 Way, N/Open, Brass & Viton, 0 to 6 Bar (C13 coil excl)

PRICE FROM: R 1083.30
QUANTITY:


QUANTITY:

P3W23B BRASS Series ,Diaphragm Assisted Lift (N/Open), Solenoid Valves

P3W23 Series - 2/2 N/Open Assisted Lift Diaphragm Valves. The Valve Body is made of BRASS. Seals available is NBR, VITON and EPDM. The Operating pressure Range is 0 to 6 Bar. Suitable for Gravity feed applications(Zero) 0 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 40 Centistokes.


View PDF data sheet for specific information.
P3W23B BRASS Series ,Diaphragm Assisted Lift (N/Open), Solenoid Valves

P3W23 Series - 2/2 N/Open Assisted Lift Diaphragm Valves. The Valve Body is made of BRASS. Seals available is NBR, VITON and EPDM. The Operating pressure Range is 0 to 6 Bar. Suitable for Gravity feed applications(Zero) 0 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 40 Centistokes.


View PDF data sheet for specific information.

1/2" BSP, Brass & Viton, N/Open,0 to 5(DC) 7(AC) Bar (C14/15DX coil excl)
PART NO : P3W23BH15S04
SIZE/DESCRIPTION:
1/2" BSP, Brass & Viton, N/Open,0 to 5(DC) 7(AC) Bar (C14/15DX coil excl)

PRICE FROM: R 1412.00
QUANTITY:


QUANTITY:
PART NO : P3W23BH20S06
SIZE/DESCRIPTION:
3/4" BSP, Brass & Viton, N/Open,0 to 5(DC) 7(AC) Bar (C14/15DX coil excl)

PRICE FROM: R 1552.00
QUANTITY:


QUANTITY:
PART NO : P3W23BH25S10
SIZE/DESCRIPTION:
1" BSP, Brass & Viton, N/Open,0 to 5(DC) 7(AC) Bar (C14/15DX coil excl)

PRICE FROM: R 1882.00
QUANTITY:


QUANTITY:

PLP23 Series, N/Open, Pilot Operated, High Pressure Brass Solenoid Valves

PLP23 Series - 2/2 N/Open Pilot Operated Diaphragm Valves. The Valve Body is made of Brass with a Viton seal. The Operating pressure Range is 0,3 to 8/13 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses which is compatible with Brass and Viton. The only further requirement is viscosity below 40 Centistokes and a Minimum available pressure of 0,3 Bar(3 Meter Head). Thus not suitable for Gravity feed applications.


View PDF data sheet for specific information.
PLP23 Series, N/Open, Pilot Operated, High Pressure Brass Solenoid Valves

PLP23 Series - 2/2 N/Open Pilot Operated Diaphragm Valves. The Valve Body is made of Brass with a Viton seal. The Operating pressure Range is 0,3 to 8/13 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses which is compatible with Brass and Viton. The only further requirement is viscosity below 40 Centistokes and a Minimum available pressure of 0,3 Bar(3 Meter Head). Thus not suitable for Gravity feed applications.


View PDF data sheet for specific information.

1/2" BSP, Brass & Viton, 0.5 to 10Bar (C14/15 coil excl)
PART NO : PLP23BH15S04V
SIZE/DESCRIPTION:
1/2" BSP, Brass & Viton, 0.5 to 10Bar (C14/15 coil excl)

PRICE FROM: R 1505.35
QUANTITY:


QUANTITY:
PART NO : PLP23BH20S06V
SIZE/DESCRIPTION:
3/4" BSP, Brass & Viton, 0.5 to 10Bar (C14/15 coil excl)

PRICE FROM: R 1707.75
QUANTITY:


QUANTITY:
PART NO : PLP23BH25S10V
SIZE/DESCRIPTION:
1" BSP, Brass & Viton, 0.5 to 13Bar (C14/15 coil excl)

PRICE FROM: R 2208.00
QUANTITY:


QUANTITY:
PART NO : PLP23BH40S14V
SIZE/DESCRIPTION:
11/2" BSP, Brass & Viton, 0.5 to 8Bar (C14/15 coil excl)

PRICE FROM: R 3777.75
QUANTITY:


QUANTITY:
PART NO : PLP23BH50S20V
SIZE/DESCRIPTION:
2" BSP, Brass & Viton, 0.5 to 8Bar (C14/15 coil excl)

PRICE FROM: R 5447.55
QUANTITY:


QUANTITY:

PLM23 Stainless Steel Series, N/Open, Direct Acting Solenoid Valve

PLM23 Stainless Steel Series - 2/2 N/Open Direct Acting Solenoid Valve. The Valve Body is made of Stainless Steel 316. Seals available is VITON. Orifice 3 mm. The operating depends on orifice and voltage - see PDF for more technical specs.


View PDF data sheet for specific information.
PLM23 Stainless Steel Series, N/Open, Direct Acting Solenoid Valve

PLM23 Stainless Steel Series - 2/2 N/Open Direct Acting Solenoid Valve. The Valve Body is made of Stainless Steel 316. Seals available is VITON. Orifice 3 mm. The operating depends on orifice and voltage - see PDF for more technical specs.


View PDF data sheet for specific information.

1/4" BSP, Stainless Steel & Viton, Orf: 3mm, 0 to 12 Bar (C13D Coil excl)
PART NO : PLM23SH03S02V
SIZE/DESCRIPTION:
1/4" BSP, Stainless Steel & Viton, Orf: 3mm, 0 to 12 Bar (C13D Coil excl)

PRICE FROM: R 1063.00
QUANTITY:


QUANTITY:

PLA23 Series, N/OPEN, Stainless Solenoid Valves

PLA23 Series, N/OPEN, Stainless Solenoid Valves The Valve Body is made of 304 Stainless Steel. Piston seal are PTFE and Pilot seat are Viton seal. The Operating pressure Range is(Sizes up to 25mm)0,5 to 10 Bar differential Pressure.(Maximum System/Body Pressure 12 Bar). For sizes Larger than 25mm the Maximum Differential Pressure is 6 Bar(System Pressure Still 12 Bar) Temperature up to 130 Deg Celsius. (STEAM up to 2.5 Bar and 130 Deg Celcius Allowed- STEAM COIL ONLY)


View PDF data sheet for specific information.
PLA23 Series, N/OPEN, Stainless Solenoid Valves

PLA23 Series, N/OPEN, Stainless Solenoid Valves The Valve Body is made of 304 Stainless Steel. Piston seal are PTFE and Pilot seat are Viton seal. The Operating pressure Range is(Sizes up to 25mm)0,5 to 10 Bar differential Pressure.(Maximum System/Body Pressure 12 Bar). For sizes Larger than 25mm the Maximum Differential Pressure is 6 Bar(System Pressure Still 12 Bar) Temperature up to 130 Deg Celsius. (STEAM up to 2.5 Bar and 130 Deg Celcius Allowed- STEAM COIL ONLY)


View PDF data sheet for specific information.

1/2" BSP, Normally Open Stainless Steel 304 & PTFE Piston, 0,5 to 10 Bar, 130 Deg Celsius. (C14/C15 coil excl)
PART NO : PLA23SH15S04PT
SIZE/DESCRIPTION:
1/2" BSP, Normally Open Stainless Steel 304 & PTFE Piston, 0,5 to 10 Bar, 130 Deg Celsius. (C14/C15 coil excl)

PRICE FROM: R 2640.00
QUANTITY:


QUANTITY:
PART NO : PLA23SH20S06PT
SIZE/DESCRIPTION:
3/4" BSP, Normally Open Stainless Steel 304 & PTFE Piston, 0,5 to 10 Bar, 130 Deg Celsius. (C14/C15 coil excl)

PRICE FROM: R 2890.00
QUANTITY:


QUANTITY:
PART NO : PLA23SH25S10PT
SIZE/DESCRIPTION:
1" BSP, Normally Open Stainless Steel 304 & PTFE Piston, 0,5 to 10 Bar, 130 Deg Celsius. (C14/C15 coil excl)

PRICE FROM: R 3262.00
QUANTITY:


QUANTITY:
PART NO : PLA23SH40S14PT
SIZE/DESCRIPTION:
11/2" BSP, Normally Open Stainless Steel 304 & PTFE Piston, 0,5 to 6 Bar, 130 Deg Celsius. (C14/C15 coil excl)

PRICE FROM: R 4790.00
QUANTITY:


QUANTITY:
PART NO : PLA23SH50S20PT
SIZE/DESCRIPTION:
2" BSP, Normally Open Stainless Steel 304 & PTFE Piston, 0,5 to 6 Bar, 130 Deg Celsius. (C14/C15 coil excl)

PRICE FROM: R 6035.00
QUANTITY:


QUANTITY:

PVX2XX Series Electric Ball Valves(N/Closed or N/Open)

PVX2XX Series ,2/2 Way Stainless Steel FULL BORE Electric Ball Valves. (PVC-N/Closed)(PVO-N/Open) These Valves have switches that switch them off when they reach end of rotation. The Dc Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP62 Body Material Stainless Steel 304 Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: 3,5,9,12,15,24VDC and 220VAC(See Specific Stock Item) Applications: It is used for Industrial Line Shutoff,home water, Solar water heaters and small automatic control equipment.


View PDF data sheet for specific information.
PVX2XX Series Electric Ball Valves(N/Closed or N/Open)

PVX2XX Series ,2/2 Way Stainless Steel FULL BORE Electric Ball Valves. (PVC-N/Closed)(PVO-N/Open) These Valves have switches that switch them off when they reach end of rotation. The Dc Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP62 Body Material Stainless Steel 304 Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: 3,5,9,12,15,24VDC and 220VAC(See Specific Stock Item) Applications: It is used for Industrial Line Shutoff,home water, Solar water heaters and small automatic control equipment.


View PDF data sheet for specific information.

1/2" FULL BORE BSP. 2/2 Motorised Stainless Steel Ball Valve-XXX-VAC/DC. IP62, Position Indicator
PART NO : PVX215WXXDX
SIZE/DESCRIPTION:
1/2" FULL BORE BSP. 2/2 Motorised Stainless Steel Ball Valve-XXX-VAC/DC. IP62, Position Indicator

PRICE FROM: R 2242.00 to 2933.00(Min 2 Items Ordered)
QUANTITY:


QUANTITY:
PART NO : PVX220WXXDX
SIZE/DESCRIPTION:
3/4" FULL BORE BSP. 2/2 Motorised Stainless Steel Ball Valve-XXX-VAC/DC. IP62, Position Indicator

PRICE FROM: R 3277.50 to 3358.00 (Min 2 Items Ordered)
QUANTITY:


QUANTITY:
PART NO : PVX225WXXDX
SIZE/DESCRIPTION:
1" FULL BORE BSP. 2/2 Motorised Stainless Steel Ball Valve-XXX-VAC/DC. IP62, Position Indicator

PRICE FROM: R 4100.00 to 4700.00 (Min 2 Items Ordered)
QUANTITY:


QUANTITY:
PART NO : PVX240WXXDX
SIZE/DESCRIPTION:
11/2"(40mm) FULL BORE BSP. 2/2 Motorised Stainless Steel Ball Valve-XXX-VAC/DC. IP62, Position Indicator

PRICE FROM: R 5157.75 to 5727.00(Min 2 Items Ordered)
QUANTITY:


QUANTITY:
PART NO : PVX250WXXDX
SIZE/DESCRIPTION:
2" FULL BORE BSP. 2/2 Motorised Stainless Steel Ball Valve-XXX-VAC/DC. IP62, Position Indicator

PRICE FROM: R 7038.00 to 7998.25 (Min 2 Items Ordered)
QUANTITY:


QUANTITY:

PNEUMATRON VALVE COILS/SOLENOIDS

MATCH YOUR COILS BELOW TO YOUR VALVE TYPE PDS22, P2W22......

PNEUMATRON VALVE COILS/SOLENOIDS

MATCH YOUR COILS BELOW TO YOUR VALVE TYPE PDS22, P2W22......


C13 Coil & DIN Plug for PLM22, PLM23, PLT32, PLV32, PLV33, PQS22, PDS22. XXX-Specifies Voltage
PART NO : C13DX-XXX
SIZE/DESCRIPTION:
C13 Coil & DIN Plug for PLM22, PLM23, PLT32, PLV32, PLV33, PQS22, PDS22. XXX-Specifies Voltage

PRICE FROM: R 468.05
QUANTITY:


QUANTITY:
PART NO : C15DX-XXX
SIZE/DESCRIPTION:
C15 Coil & DIN Plug for P2W22, P3W23, PLP23, PLA22, PLG22. XXX-Specifies Voltage

PRICE FROM: R 512.90
QUANTITY:


QUANTITY:
PART NO : C14DX-XXX
SIZE/DESCRIPTION:
C14 Coil & DIN Plug for P2W22, P3W23, PLP23, PLA22, PLG22. XXX-Specifies Voltage

PRICE FROM: R 512.90
QUANTITY:


QUANTITY:
PART NO : C12DX-XXX
SIZE/DESCRIPTION:
1/2" to 2" PD22 Valves.(XXX Indicates Voltage)

PRICE FROM: R 593.40
QUANTITY:


QUANTITY:
PART NO : C12HDX-XXX
SIZE/DESCRIPTION:
Coil & Plug for 1/2" to 2" PSP22 STEAM Valves.(XXX Indicates Voltage)

PRICE FROM: R 682.41
QUANTITY:


QUANTITY:
PART NO : C20DX-XXX
SIZE/DESCRIPTION:
1/2" PD5422 Valves.(XXX Indicates Voltage)

PRICE FROM: R 437.00
QUANTITY:


QUANTITY:
PART NO : C19DX-XXX
SIZE/DESCRIPTION:
C19 Coil & DIN Plug for PSM22, PCG23 Valves. XXX-Specifies Voltage

PRICE FROM: R 485.00
QUANTITY:


QUANTITY:
PART NO : C11DX-XXX
SIZE/DESCRIPTION:
C11 Coil & Plug for PSM222 or PX22(1/4" & 1/8") Valves.XXX-Specifies Voltage.

PRICE FROM: R 182.00
QUANTITY:


QUANTITY:
PART NO : CDHRS 30A-XXX
SIZE/DESCRIPTION:
CDHRS Coil & Plug for DHD/PD22MH VALVES( 400325-117-1)XXX-Specifies Voltage.

PRICE FROM: R 593.40
QUANTITY:


QUANTITY:
